PART 2: CX-Server PLC Tools
CHAPTER 12 – PLC Backup Tool OMRON
CX-Server PLC Tools_Page 158
Detailed Display of the Comparison Results
1, 2, 3…
1. Double-click the Unit in the comparison results list.
The Details of Unmatched Item Dialog Box will be displayed.
The data saved in the
Unit is displayed.
Whether the data matches
is displayed.
Example 1: CJ2H-CPU67H CPU Unit
Example 2: CJ1W-CLK21 CPU Bus Unit
To Next Page
