Omron F3SJ Series - Wiring; Wiring Precautions

137
F3SJ-A
User’s Manual
Chapter4 Dimensions
Wiring/Installation
E
Dimensions A to C
AC + 65
BC + 34
C 4-digit number of the model name (protective height)
F39-LJ5
Outward-facing mounting
Use standard
brackets
B
20
4-M5
30
20
5.55.5
21
B
5.8
4.2
A
30
15.5
(15.5)
19.9
32
2
C (Protective height)
(Unit: mm)
Material: Stainless steel
dia.6.5
dia.9
44
44.9
