Chapter4 Dimensions
Wiring/Installation
E
F3SN replacement correspondence table (F3SN mounting holes can be used without modification)
•When replacing F3SN-N14 with F3SJ-AN14
For lengths greater than the F3SN-0234N14:
Add 11 to the F3SN's 4-digit number and apply it as the F3SJ's 4-digit number, and then replace with
the standard brackets included with the product.
[Selection example] F3SN-A0315N14 becomes F3SJ-A0326N14 (replace with standard brackets)
- The protective height is 11mm longer.
- Replace with outward-facing mounting of F39-LJ5 when you want to set the detection surface height to be same as
the F3SN.
However, the F39-LJ5 and intermediate mounting brackets cannot be mounted simultaneously, so set the protective
height to 600mm or less.
•When replacing F3SN-N25 with F3SJ-AN20
For lengths greater than the F3SN-0262N25:
Subtract 17 from the F3SN's 4-digit number and apply it as the F3SJ's 4-digit number, and then
replace with the standard brackets included with the product.
[Selection example] F3SJ-A0322N25 becomes F3SJ-A0305N20 (replace with standard brackets)
- The protective height becomes 17mm shorter.
- Replace with outward-facing mounting of F39-LJ5 when you want to set the detection surface height to be same as
the F3SN.
However, the F39-LJ5 and intermediate mounting brackets cannot be mounted simultaneously, so set the protective
height to 600mm or less.
F3SN Replacement F3SJ
Replacement method
using F39-LJ5
Model name Protective height Model name Protective height
F3SN-0153N14 153 - - -
F3SN-0180N14 180 F3SJ-A0245N14 245 Inward-facing mounting
F3SN-0189N14 189 F3SJ-A0245N14 245 Inward-facing mounting
F3SN-0198N14 198 F3SJ-A0245N14 245 Inward + outward-facing
mounting
F3SN-0207N14 207 F3SJ-A0245N14 245 Inward + outward-facing
mounting
F3SN-0216N14 216 F3SJ-A0245N14 245 Outward-facing mounting
F3SN-0225N14 225 F3SJ-A0245N14 245 Outward-facing mounting
F3SN Replacement F3SJ
Replacement method
using F39-LJ5
Model name Protective height Model name Protective height
F3SN-0187N25 187 - - -
F3SN-0217N25 217 F3SJ-A0260N20 260 Inward-facing mounting
F3SN-0232N25 232 F3SJ-A0260N20 260 Inward + outward-facing
mounting
F3SN-0247N25 247 F3SJ-A0245N20 245 Outward-facing mounting
