144
Chapter4 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
F3W-C replacement correspondence table (F3W-C mounting holes can be used without modification)
•When replacing F3W-C with F3SJ-A30
Target F3W-C4
*1 New mounting holes are required for intermediate mounting brackets.
F3SN Replacement F3SJ
Model Protective height Model Protective height
F3W-C044 120 - -
F3W-C084 280 F3SJ-A032030 320
F3W-C124 440 F3SJ-A047030 470
F3W-C164 600 F3SJ-A062030 *1 620
F3W-C204 760 F3SJ-A079530 *1 795
F3W-C244 920 F3SJ-A094530 *1 945
