Omron MX2 Series User Manual

4 Parameter List
4 - 19
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Window
comparator
b060
Window Comparator
O Upper Limit Level
Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Lower limit level + Hysteresis
width  2
100.
Enabled
%
P. 7-90
b061
Window Comparator
O Lower Limit Level
Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Upper limit level − Hysteresis
width  2
0.
Enabled
%
b062
Window Comparator
O Hysteresis Width
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0. to 10.
Upper limit: (Upper limit level − Lower
limit level) / 2
0.
Enabled
%
b063
Window Comparator
OI Upper Limit Level
Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Lower limit level + Hysteresis
width  2
100.
Enabled
%
b064
Window Comparator
OI Lower Limit Level
Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Upper limit level − Hysteresis
width  2
0.
Enabled
%
b065
Window Comparator
OI Hysteresis Width
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0. to 10.
Upper limit: (Upper limit level − Lower
limit level) / 2
0.
Enabled
%
b070
Analog Operation
Level at O
Disconnection
0. to 100.
255: no (Disabled)
no
Enabled
%
b071
Analog Operation
Level at OI Discon-
nection
0. to 100.
255: no (Disabled)
no
Enabled
%
4
4-3 Extended Function Mode
4-3-2 Group b: Detailed Function Parameters

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
