Omron MX2 Series User Manual

4 Parameter List
4 - 28
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Level and output
terminal
status
C042
Arrival Frequency
During Acceleration 1
0.0 Not output arrival signal
0: during acceleration.
0.01 to 590.00
0.00
Enabled
Hz
P. 7-83
C043
Arrival Frequency
During
Deceleration 1
0.0 Not output arrival signal
0: during deceleration.
0.01 to 590.00
0.00
Enabled
Hz
C044
PID Deviation Exces-
sive Level
0.0 to 100.0
3.0
Enabled
%
P. 7-44
C045
Arrival Frequency
During Acceleration 2
0.0 Not output arrival signal during
0: acceleration.
0.01 to 590.00
0.00
Enabled
Hz
P. 7-83
C046
Arrival Frequency
During
Deceleration 2
0.0 Not output arrival signal during
0: deceleration.
0.01 to 590.00
0.00
Enabled
Hz
C047
Pulse Train Output
EO Scale
0.01 to 99.99
1.00
Enabled
−
P. 7-28
C052
Feedback Compari-
son Signal Off Level
0.0 to 100.0
100.0
Enabled
%
P. 7-44
C053
Feedback Compari-
son Signal On Level
0.0 to 100.0
0.0
Enabled
%
C054
Overtorque/Under-
torque Selection
00: Overtorque
01: Undertorque
00
Enabled
−
P. 6-15
C055
Overtorque/Under-
torque Level
(Forward Power Run-
ning)
0. to 200.
100.
Enabled
%
C056
Overtorque/Under-
torque Level
(Reverse Regenera-
tion)
100.
Enabled
C057
Overtorque/Under-
torque Level
(Reverse Power
Running)
100.
Enabled
C058
Overtorque/Under-
torque Level
(Forward Regenera-
tion)
100.
Enabled
C059
Overtorque/Under-
torque Signal Opera-
tion
00: Enabled during acceleration/decel-
eration and constant speed
01: Enabled only during constant speed
01
Enabled
−
C061
Electronic Thermal
Warning Level
0. to 100.
90.
Enabled
%
P. 7-77
C063
0 Hz Detection Level
0.00 to 100.00
0.00
Enabled
Hz
P. 5-57
C064
Cooling Fin Over-
heat Warning Level
0. to 110.
100.
Enabled
°C
P. 7-88

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
