Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
The following parameter data ranges are changed to extend the support range of applications.
Parameter
No.
Function name
Data range
3G3MX2-E
3G3MX2-EV2
d001
Output Frequency Monitor
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
d002
Output Current Monitor
0.00 to 655.30
0.00 to 655.35
d004
PID Feedback Value Monitor
0.00 to 10000.00
0.00 to 9999.00
d007
Output Frequency Monitor (After
Conversion)
0.00 to 39996.00 (57994.20)
*1
0.00 to 58994.10
d008
Real Frequency Monitor
(-580.00)
*1
-400.00 to 400.00
(580.00)
*1
-590.00 to 590.00
d015
Integrated Power Monitor
0.0 to 999900.0
0.0 to 1000000.0
d016
Total RUN Time Monitor
0 to 999900
0 to 1000000
d017
Total Power ON Time Monitor
0 to 999900
0 to 1000000
d025
User Monitor 0
(DriveProgramming)
-2147483647 to 2147483647
-2147483648 to 2147483647
d026
User Monitor 1
(DriveProgramming)
d027
User Monitor 2
(DriveProgramming)
d081
Fault Monitor 1 (Latest)
Fault Factor: E00 to E83, E99
Output Frequency: 0.00 to
580.00
Output Current: 0.00 to 655.30
Total RUN Time: 0 to 999900
Total Power ON Time: 0 to
999900
Fault Factor: E00 to E83, E99
Output Frequency: 0.00 to
590.00
Output Current: 0.00 to 655.35
Total RUN Time: 0 to 1000000
Total Power ON Time: 0 to
1000000
d082
Fault Monitor 2
d083
Fault Monitor 3
d084
Fault Monitor 4
d085
Fault Monitor 5
d086
Fault Monitor 6
F001
Output Frequency Setting/Moni-
tor
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A003
1st Base Frequency
0.0 to 400.0 (580.0)
*1
30.0 to 590.0
A203
2nd Base Frequency
0.0 to 400.0 (580.0)
*1
30.0 to 590.0
A004
1st Maximum Frequency
0.0 to 400.0 (580.0)
*1
30.0 to 590.0
A204
2nd Maximum Frequency
0.0 to 400.0 (580.0)
*1
30.0 to 590.0
A011
O Start Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A012
O End Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A020
1st Multi-step Speed Reference
0
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A220
2nd Multi-step Speed Reference
0
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A038
Jogging Frequency
0.00 to 9.99 (100.00)
*1
0.00 to 10.00 (100.00)
*1
A061
1st Frequency Upper Limit
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A261
2nd Frequency Upper Limit
A062
1st Frequency Lower Limit
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A262
2nd Frequency Lower Limit
A063
Jump Frequency 1
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A065
Jump Frequency 2
A067
Jump Frequency 3
A069
Acceleration Stop Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
*1. In high-frequency mode.
Change of Parameter Setting Ranges

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
