1 Overview
1 - 29
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Data range
3G3MX2-E
3G3MX2-EV2
A095
1st 2-step Acceleration Fre-
quency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A295
2nd 2-step Acceleration Fre-
quency
A096
1st 2-step Deceleration Fre-
quency
A296
2nd 2-step Deceleration Fre-
quency
A101
OI Start Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A102
OI End Frequency
A145
Frequency Addition Amount
Setting
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A154
Deceleration Stop Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A156
PID Sleep Operation Level
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A161
VR Start Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
A162
VR End Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
b007
Frequency Pull-in Lower Limit
Frequency
0.00 to 400.00 (580.00)
*1
0.00 to 590.00
b015
Free-electronic Thermal Fre-
quency 1
0 to 400 (580)
*1
0 to 590
b017
Free-electronic Thermal Fre-
quency 2
b019
Free-electronic Thermal Fre-
quency 3
b031
Soft Lock Selection
00 to 03 or 10
00 to 03
b037
Display Selection
00 to 05
00 to 03 or 05
b051
Starting Voltage on Power Inter-
ruption
0 to 1000
200-V class: 0.0 to 400.0
400-V class: 0.0 to 800.0
b052
Deceleration Hold Level on
Power Interruption
0 to 1000
200-V class: 0.0 to 400.0
400-V class: 0.0 to 800.0
b082
Starting Frequency
0.01 to 9.99 (100.00)
*1
0.01 to 10.00 (100.00)
*1
b096
Regenerative Braking ON Level
200-V class: 330 to 380
400-V class: 660 to 760
200-V class: 330 to 400
400-V class: 660 to 800
b100
Free V/f Frequency 1
0 to 580
0 to 590
b102
Free V/f Frequency 2
b104
Free V/f Frequency 3
b106
Free V/f Frequency 4
b108
Free V/f Frequency 5
b110
Free V/f Frequency 6
b112
Free V/f Frequency 7
b125
Brake Release Frequency
0.00 to 400.00
0.00 to 590.00
b127
Brake Force Frequency
0.00 to 400.00
0.00 to 590.00
b131
Overvoltage Suppression Level
During Deceleration
200-V class: 330 to 395
400-V class: 660 to 790
200-V class: 330 to 400
400-V class: 660 to 800
C003
Multi-function Input 3 Selec- tion
00 to 09, 11 to 16, 18 to 24, 27
to 29, 31 to 42, 44, 46, 47, 50
to 53, 56 to 62, 65 to 70, 73,
77, 81 to 86, 91
255: no
00 to 09, 11 to 16, 18, 20 to 24,
27 to 29, 31 to 42, 44, 46, 47,
50 to 53, 56 to 62, 65 to 70,
73, 81 to 86, 91
255: no
*1. In high-frequency mode.
1
1-5 Comparison with Previous
Model

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
