327
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
BIN(23) When converting a word to a word 40.40 1.125
When converting :DM to :DM 74.80
BCD(24) When converting a word to a word 38.40 1.125
When converting :DM to :DM 72.80
ASL(25) When shifting a word 21.20 0.75
When shifting :DM 38.20
ASR(26) When shifting a word 21.20 0.75
When shifting :DM 38.20
ROL(27) When rotating a word 21.80 0.75
When rotating :DM 39.00
ROR(28) When rotating a word 21.80 0.75
When rotating :DM 39.00
COM(29) When inverting a word 21.90 0.75
When inverting :DM 39.30
ADD(30) Constant + word → word 40.10 1.5
Word + word→ word 42.50
:DM + :DM → :DM 94.10
SUB(31) Constant – word → word 40.10 1.5
Word – word→ word 42.50
:DM – :DM → :DM 94.10
MUL(32) Constant x word → word 56.90 1.5
Word x word→ word 59.30
:DM x :DM → :DM 110.90
DIV(33)
Word ÷ constant → word
56.90 1.5
Word ÷ word→ word
59.10
:DM ÷ :DM → :DM
110.70
ANDW(34) Constant AND word → word 34.10 1.5
Word AND word→ word 37.10
:DM AND :DM → :DM 88.70
ORW(35) Constant OR word → word 34.10 1.5
Word OR word→ word 36.70
:DM OR :DM → :DM 88.30
XORW(36) Constant XOR word → word 34.10 1.5
Word XOR word→ word 36.70
:DM XOR :DM → :DM 88.30
XNRW(37) Constant XNOR word → word 34.30 1.5
Word XNOR word→ word 36.90
:DM XNOR :DM → :DM 88.50
INC(38) When incrementing a word 23.70 0.75
When incrementing :DM 41.10
DEC(39) When decrementing a word 24.30 0.75
When decrementing :DM 41.70
STC(40) --- 12.20 0.375
CLC(41) --- 12.30 0.375
TRSM(45) --- 27.70 27.70
MSG(46) Designated as DM 23.20 0.75
Designated as :DM 40.80
Instruction Execution Times Section 6-3
