328
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
ADB(50) Constant + word → word 43.20 1.5
Word + word → word 45.80
:DM + :DM → :DM 97.40
SBB(51) Constant – word → word 43.20 1.5
Word – word → word 45.80
:DM – :DM → :DM 97.40
MLB(52) Constant x word → word 36.00 1.5
Word x word → word 38.50
:DM x :DM → :DM 91.10
DVB(53)
Word ÷ constant → word
36.70 1.5
Word ÷ word → word
39.30
:DM ÷ :DM → :DM
90.80
ADDL(54) Word + word → word 45.50 1.5
:DM + :DM → :DM 99.00
SUBL(55) Word – word → word 45.50 1.5
:DM – :DM → :DM 99.00
MULL(56) Word x word → word 155.90 1.5
:DM x :DM → :DM 209.50
DIVL(57)
Word ÷ word → word
166.10 1.5
:DM ÷ :DM → :DM
219.70
BINL(58) When converting words to words 58.70 1.125
When converting :DM to :DM 93.50
BCDL(59) When converting words to words 47.30 1.125
When converting :DM to :DM 82.20
XFER(70) When transferring 1 word 54.80 1.5
When transferring 1,024 words using
:DM
2.40 ms
When transferring 6,143 words using
:DM
13.99 ms
BSET(71) When setting a constant to 1 word 37.70 1.5
When setting :DM ms to 1,024 words
using :DM
26.20
When setting :DM ms to 6,144 words
using :DM
95.80
ROOT(72) When taking root of word and placing in a
word
68.60 1.125
When taking root of 99,999,999 in :DM
and placing in :DM
137.80
XCHG(73) Between words 33.50 1.125
Between :DM 68.50
SLD(74) When shifting 1 word 34.00 1.125
When shifting 1,024 DM words using :DM
4.35 ms
When shifting 6,144 DM words using :DM
25.93 ms
SRD(75) When shifting 1 word 34.00 1.125
When shifting 1,024 DM words using :DM
4.35 ms
When shifting 6,144 DM words using :DM
26.01 ms
MLPX(76) When decoding word to word 86.80 1.5
When decoding :DM to :DM 178.20
Instruction Execution Times Section 6-3
