Omron SYSMAC C200HS User Manual

330
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
TERM(––)
Default code: (48)
--- 16.40 1.5
CMPL(––) When comparing words to words 51.40 1.5
Default code: (60) When comparing :DM to :DM 85.90
MPRF(––) 1 Unit 33.70 1.5
Default code: (61) 10 Units 74.20
XFRB(––) Sending 1 bit from word to word 45.50 1.5
Default code: (62) Sending FF bits from :DM to :DM 241.90
LINE(––)
Default code: (63)
When transferring from words to a
constant
102.90 1.5
When transferring from words to a word 106.40
When transferring :DM to :DM 293.80
COLM(––)
Default code: (64)
When transferring from a constant to
words
115.20 1.5
When transferring from a word to words 118.70
When transferring :DM to :DM 303.10
SEC(––) DM to DM 78.50 1.5
Default code: (65) :DM to :DM 112.90
HMS(––) DM to DM 80.00 1.5
Default code: (66) :DM to :DM 114.50
BCNT(––) Constant for SV 69.56 1.5
Default code: (67) :DM for SV 37.52 ms
BCMP(––)
Default code: (68)
Comparing constant to word-designated
table
105.00 1.5
To a word after comparing with a word 107.40
Comparing : DM → : DM-designated table
166.50
APR(––) SIN designation 43.90 1.5
Default code: (69) :DM for SV 740.70
TTIM(––)
Default code: (87)
Setting to a constant 43.50 Constant input OFF: 36.9
R: 38.4
IL: 36.8
JPM: 36.8
Setting to :DM 81.70 Constant input OFF: 75.1
R: 76.6
IL: 75.0
JPM: 75.1
ZCP(––)
Default code: (88)
Comparing a constant to a word 35.40 1.5
Comparing a word to a word 38.00
Comparing :DM to a :DM 89.70
INT(––) Word for SV 21.70 to 47.40 1.5
Default code: (89) :DM for SV 21.70 to 64.60
TKY(––) Input to DM 63.10 1.5
Input to :DM 97.90
RXD(––) When designating a word 76.50 1.5
When designating :DM 128.50
TXD(––) When designating a word 65.30 1.5
When designating :DM 125.30
7SEG(––) Word-designated 4 digits 49.10 to 55.40 21.70
Instruction Execution Times Section 6-3
