331
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
:DM-designated 4 digits 66.60 to 72.80
Word-designated 8 digits 56.70 to 64.80
:DM-designated 8 digits 74.20 to 82.30
FPD(––) Word designation, code output 121.00 to 147.50 17.30
:DM designation, message output 170.50 to 228.80
SRCH(––) Constant for SV 78.50 1.5
:DM for SV 2.11 ms
:DM for SV 12.10 ms
MAX(––) DM search 57.20 1.5
:DM search 2.05 ms
MIN(––) DM search 57.20 1.5
:DM search 2.05 ms
SUM(––) DM add 60.10 1.5
:DM add 1.80 ms
FCS(––) Add a word → word 52.90 1.5
Add 999 words → :DM 1.41 ms
HEX(––) DM conversion 66.70 1.5
:DM conversion 169.90
AVG(––) Average of an operation 61.40 19.7
Average of 64 operations 223.70
PID(––) When designating a word 83.00 1.5
When designating :DM 138.00
XDMR(––) Constant for SV 74.20 1.5
Word for SV 2.32 ms
:DM for SV 6.89 ms
MTR(––) Input to DM 54.60 to 63.60 21.7
Input to :DM 72.00 to 81.20
ADBL(––) DM + DM → DM 72.20 1.5
:DM + :DM → :DM 123.30
SBBL(––) DM – DM → DM 71.70 1.5
:DM – :DM → :DM 123.30
MBS(––) Constant x word → word 50.20 1.5
DM x DM → DM 52.80
:DM x :DM → :DM 104.30
DBS(––) Constant ÷ word → word 51.20 1.5
DM ÷ DM → DM 53.70
:DM ÷ :DM → :DM 106.20
MBSL(––) DM x DM → DM 81.90 1.5
:DM x :DM → :DM 133.50
DBSL(––) DM ÷ DM → DM 90.70 1.5
:DM ÷ :DM → :DM 143.70
CPS(––) When comparing two constants 34.20 1.5
When comparing DM to DM 29.70
When comparing DM to :DM 64.80
CPSL(––) When comparing two DM 50.90 1.5
When comparing two :DM 86.10
Instruction Execution Times Section 6-3
