Example The
following example shows the displays that appear when Restore Status
is
carried out normally.
00000
00000
00000FORCE RELE?
00000FORCE RELE
END
7-1-4 Hexadecimal/BCD Data Modification
When
the Bit/Digit Monitor operation is
being performed and a BCD or hexadeci
-
mal
value is leftmost on the display
,
CHG can be input to change the value. SR
words cannot be changed.
If
a timer or counter
is leftmost on the display
, the PV will be displayed and will be
the
value changed. See
7-1-13
Changing T
imer/Counter SV
for
the procedure to
change SV. PV can be changed in MONITOR mode only when the timer or
counter is operating.
To
change contents of
the leftmost word address, press CHG, input the desired
value, and press WRITE
Key Sequence
Word currently
monitored on
left of display
.
[ Data ]
Monitoring Operation and Modifying Data Section 7-1
