Appendix EPC Setup
462
Word(s) Bit(s) Function Default
Interrupt/Refresh Processing (DM 6620 to DM 6622)
The following settings are effective after transfer to the PC the next time operation is started.
DM 6620 00 to 09 Special I/O Unit cyclic refresh (Bit number corresponds to unit number, PC
Link Units included)
0: Enable cyclic refresh and I/O REFRESH (IORF(97)) from main program
1: Disable (refresh only for I/O REFRESH from interrupt programs)
Disable not valid for normal (C200H) interrupt response or on Slave Racks.
Enable
10 to 1 1 Reserved ---
12 to 15 Interrupt response
0: Normal (C200H compatible)
1: High-speed (C200HS)
Normal
DM 6621 00 to 07 Reserved ---
08 to 15 Special I/O Unit refresh (PC Link Units included)
00: Enable refresh for all Special I/O Units
01: Disable refresh for all Special I/O Units (but, not valid on Slave Racks)
Enable
DM 6622 00 to 07 Scheduled interrupt time unit
00: 10 ms
01: 1 ms
10 ms
08 to 15 Scheduled interrupt time unit enable
00: Disable (10 ms)
01: Enable
DM 6623 to
DM 6644
00 to 15 Reserved ---
RS-232C Port Settings (DM 6645 to DM 6649)
The following settings are effective after transfer to the PC.
DM 6645 00 to 07 Port settings
00: Standard (1 start bit, 7-bit data, even parity, 2 stop bits, 9,600 bps)
01: Settings in DM 6646
Standard
08 to 1 1 Words linked for 1:1 link
0: LR 00 to LR 63; 1: LR 00 to LR 31; 2: LR 00 to LR 15
LR 00 to LR 63
12 to 15 Communications mode
0: Host link; 1: RS-232C; 2: 1-to-1 link slave; 3: 1-to-1 link master;
4: NT (PT) link
Host Link
DM 6646 00 to 07 Baud rate
00: 1.2K, 01: 2.4K, 02: 4.8K, 03: 9.6K, 04: 19.2K
1.2 K
08 to 15 Frame format
Start Length Stop Parity
00: 1 bit 7 bits 1 bit Even
01: 1 bit 7 bits 1 bit Odd
02: 1 bit 7 bits 1 bit None
03: 1 bit 7 bits 2 bit Even
04: 1 bit 7 bits 2 bit Odd
05: 1 bit 7 bits 2 bit None
06: 1 bit 8 bits 1 bit Even
07: 1 bit 8 bits 1 bit Odd
08: 1 bit 8 bits 1 bit None
09: 1 bit 8 bits 2 bit Even
10: 1 bit 8 bits 2 bit Odd
1
1: 1 bit 8 bits 2 bit None
1 start bit, 7-bit
data, 1 stop bit,
even parity
DM 6647 00 to 15 Transmission delay
0000 to 9999: BCD in ms.
0 ms
