Omron SYSMAC C200HS User Manual

Appendix EPC Setup
463
Word(s) DefaultFunctionBit(s)
DM 6648 00 to 07 Node number (Host link)
00 to 31 (BCD)
0
08 to 1 1 Start code enable (RS-232C)
0: Disable; 1: Set
Disabled
12 to 15 End code enable (RS-232C)
0: Disable (number of bytes received)
1: Set (specified end code)
2: CR, LF
Disabled
DM 6649 00 to 07 Start code (RS-232C)
00 to FF (binary)
Not used
08 to 15 12 to 15 of DM 6648 set to 0:
Number of bytes received
00: Default setting (256 bytes)
01 to FF: 1 to 255 bytes
12 to 15 of DM 6648 set to 1:
End code (RS-232C)
00 to FF (binary)
Peripheral Port Settings (DM 6650 to DM 6654)
The following settings are effective after transfer to the PC.
DM 6650 00 to 07 Port settings
00: Standard (1 start bit, 7-bit data, even parity, 2 stop bits, 9,600 bps)
01: Settings in DM 6651
Standard
08 to 1 1 Reserved ---
12 to 15 Communications mode
0: Host link; 1: RS-232C
Host Link
DM 6651 00 to 07 Baud rate
00: 1.2K, 01: 2.4K, 02: 4.8K, 03: 9.6K, 04: 19.2K
1.2 K
08 to 15 Frame format
Start Length Stop Parity
00: 1 bit 7 bits 1 bit Even
01: 1 bit 7 bits 1 bit Odd
02: 1 bit 7 bits 1 bit None
03: 1 bit 7 bits 2 bit Even
04: 1 bit 7 bits 2 bit Odd
05: 1 bit 7 bits 2 bit None
06: 1 bit 8 bits 1 bit Even
07: 1 bit 8 bits 1 bit Odd
08: 1 bit 8 bits 1 bit None
09: 1 bit 8 bits 2 bit Even
10: 1 bit 8 bits 2 bit Odd
1
1: 1 bit 8 bits 2 bit None
1 start bit, 7-bit
data, 1 stop bit,
even parity
DM 6652 00 to 15 Transmission delay (Host Link)
0000 to 9999: In ms.
0 ms
DM 6653 00 to 07 Node number (Host link)
00 to 31 (BCD)
0
08 to 1 1 Start code enable (RS-232C)
0: Disable; 1: Set
Disable
12 to 15 End code enable (RS-232C)
0: Disable (number of bytes received)
1: Set (specified end code)
2: CR, LF
Disable
