Note:
The Rail Frame is spring-loaded. Hold on to the Rail Frame as it
releases from the socket frame, when rotating it to the vertical position.
Slide the carrier frame package holding the processor out.
12. Place the carrier frame package in an appropriate tray.
Chapter 5
Servicing Processors (FRU)
5-10
