Callout Indicator/LED: Color State Meaning
3 OK: green Indicates the operational state
of the server node:
• Off - AC power is either
not present or the Oracle
ILOM service processor
(SP) boot process is not
complete.
• Steady blink - Standby
power is on and the
Oracle ILOM SP is
running, but the server
host power is off.
• Slow blink - Startup/
shutdown sequence has
been initiated on the
server host. During
startup, the power-on self
tests are running on the
system. During shutdown,
the server host is shutting
down and transitioning
from full power to standby
power.
• On - The server host is
powered on and is in the
process of booting or is
running the operating
system.
4
Power button Press to apply full power and
start the server host. Press
again to transition from full
power to standby power where
only the Oracle ILOM SP is
running.
5 Top fan: amber Indicates that one (or more) of
the internal fan modules has
failed.
• Off - Indicates steady
state; no service is
required.
• On - Indicates service
required; service the
failed fan module.
6 Rear PS: amber Indicates that one (or more) of
the power supplies has failed.
• Off - Indicates steady
state; no service is
required.
• On - Indicates service
required; service the
failed power supply.
Chapter 1
Oracle Database Appliance X10-S/X10-L Status Indicators
1-3
