Oracle Database Appliance X10 - Page 12

Callout Indicator/LED: Color State Meaning
7 Over temperature warning:
amber
• Off - Normal operation; no
service is required.
• On - The system is
experiencing an over
temperature warning
condition.
This is a warning indication,
not a fatal over temperature.
Failure to correct this condition
might result in the system
overheating and shutting down
unexpectedly.
8 Service processor (SP): green • Off - The service
processor (SP) is not
running.
• On - The SP is fully
operational.
• Slow blink - SP is booting.
9 DO NOT SERVICE: white Indicates that the system is
not ready to service.
• Off - Normal operation.
• On - The system is not
ready for service.
The DO NOT SERVICE
indicator is application
specific. This indicator is only
illuminated on demand by the
Host application.
10 Drive Ready-to-Remove: blue • Off - The storage drive
has not been prepared for
removal.
• On - The storage drive
can be removed safely
during a hot-plug
operation.
11 Drive Service Required:
amber
• Off - The storage drive is
operating normally.
• On - The system has
detected a fault with the
storage drive.
12 Drive OK: green • Off - Power is off or the
installed drive is not
recognized by the system.
• On - The drive is engaged
and is receiving power.
• Random blink - There is
disk activity. The indicator
blinks on and off to
indicate activity.
Chapter 1
Oracle Database Appliance X10-S/X10-L Status Indicators
1-4
