N
network cards
adding, 4-16
Network Time Protocol (NTP), 4-25
NVMe cables
description, 2-3
NVMe drives
adding to server
Oracle Database Appliance X10-S/X10-
L, 3-2
replacing in server
Oracle Database Appliance X10-S/X10-
L, 3-2
O
ODA X10 series server, 2-1
On/Standby
button, 2-9, 2-11, 6-13
Oracle ILOM
UEFI BIOS, 8-4
Oracle Integrated Lights Out Manager (ILOM)
key identity properties (KIP) for FRUID auto-
update feature, 2-6
Oracle Integrated Lights Out Manager (Oracle
ILOM)
used as diagnostic tool, 7-1
P
Pc-Check, 7-1
PCIe cards
adding, 4-16
clearing faults, 5-52
description, 2-3
installing, 4-20
removing, 4-18
replacing, 4-15
slot characteristics, 4-16
PCIe flyover cable
installing, 5-38
removing, 5-37
PCIe riser
clearing faults, 5-52
PCIe slot 6 and 7
replacing the Flyover cable, 5-37
PCIe slot Flyover cable
replacing, 5-37
PCIe slot numbering, 4-16
population rules
DIMMs, 4-10
population scenarios
DIMMs, 4-10
power
Main power mode, 2-92-11
server on, 6-13
Standby power mode, 2-12
power down server
gracefully, 2-8
immediately, 2-11
using On/Standby button, 2-9
power off the system, options, 2-7
power on
returning the system to operation, 6-1
power supplies
replacing in server, 3-1
replacing in storage shelf, 3-17
server, 3-1
status indicators
Oracle Database Appliance X10-HA, 1-7,
1-9
Oracle Database Appliance X10-S/X10-
L, 1-1, 1-5
power supply
description, 2-3
installing, 3-10
LEDs, 3-9
removing, 3-8
power-on self-test (POST), 7-1
power-on self-test (POST) events, 7-1
processor socket cover
installing, 5-40
removing, 5-40
processors
components, 5-2
description, 2-3
installing, 5-1, 5-12
maximum DIMMs supported, 4-10
overview, 5-1
package, 5-2
physical layout, 4-9
removing, 5-1, 5-3
R
rack
stability for installation, 2-12
rackmount
stabilizing the rack, 2-12, 2-14, 6-11
removing cable management arm, 2-14
removing components
4-Drive backplane, 5-23
antistatic measures, 6-2
battery, 4-22
DBP signal cable, 5-30
DIMMs, 4-13
fan module, 3-6
fan tray, 5-19
