Operand Settings
S+1
Duty ratio (Resolution of 1000 or 100)
For the control codes K0 to K27, Setting range: K0 to K1000 (0.0% to 100.0%)
For the control codes K28 to K30, Setting range: K0 to K1000 (0% to 100%)
n
Channel nos. used for PWM output:
K0 (CH0: Y0), K1 (CH1: Y2), K2 (CH3: Y4), K3 (CH4: Y6)
■
Memory area type that can be specified
Operand
WX WY WR WL SV EV DT LD I
Constant
Index
modifier
K H
S - - - - - - ● - - - - ●
n - - - - - - - - - ● ● -
■
Outline of operation
● The PWM output is performed from a specified output. The output is performed when the
execution condition is ON.
● The output frequency and cycle are determined by a specified control code. The duty ratio is
specified in the operand [S1+1].
■
Precautions during programming
● This instruction cannot be executed when a control active flag corresponding to each
channel is ON.
● The duty may be different from the set ratio according to the load voltage and load current
especially in the vicinity of minimum and maximum values. The duty can be changed for
each scan. However, the control code cannot be changed during the execution of an
instruction.
● When rewriting during RUN is performed during the operation, the PWM output stops while a
program is being rewritten.
■
Control code
S
Frequency
(Hz)
Cycle (ms) Resolution S
Frequency
(Hz)
Cycle (ms)
Resolutio
n
K0 1.5 666.67
1000
K16 2000.0 0.50
1000
K1 2.0 500.00 K17 3000.0 0.33
K2 4.0 250.00 K18 6000.0 0.17
K3 6.0 166.67 K19 12500.0 0.08
K4 8.0 125.00 K20 15000.0 0.067
K5 10.0 100.00 K21 20000.0 0.050
K6 20.0 50.00 K22 25000.0 0.040
K7 50.0 20.00 K23 30000.0 0.033
K8 100.0 10.00 K24 40000.0 0.025
K9 200.0 5.00 K25 50000.0 0.020
K10 400.0 2.50 K26 60000.0 0.017
9.1 PWM output function
9-6 WUME-FPXHPOSG-01
