Page 4-4
Before Starting Production
4-2-2 Checking Air Pressure
Make sure the pressure gauge
of MR unit shows 0.49 MPa or
above.
∗ Make sure the lever is ON.
∗ If air pressure is improper, turn the
valve and adjust it.
Unlock the valve.
Adjust the air
pressure.
Lock the valve.
Valve
Pressure
gauge
To turn the
lever ON,
throw it
up.
1D4C-827E
1E4C-AB00
ON
1
2
3
1E4C-E-OMA04-A01-00
To Next Page
