Page 3-1
Functions
• This chapter describes each function that can be chosen from the main menu as
follows.
∗ Pressing an icon displays that icon’s menu screen.
• How to see the menu configuration
Chapter 3
FUNCTIONS
1E4C-E-OMA03-A01-01
Chapter 4 DAILY PRODUCTION
The following are described in this chapter.
3-2 Production Setting
3-3 Production Information
3-4 Machine Adjustment
3-5 Machine Settings
Refer to the Maintenance Manual.
Chapter 6 FILE OPERATION
Chapter 7 DATA EDITING
Reference
Outline of function
Menu configuration
Creating Board Data
Describes setting board data.
3-2-10
Creating Board Recognition Data
Describes setting board
recognition coordinates.
3-2-11
