SAFETY PRECAUTIONS
Be sure to observe
OFF ( )
ON ( )
SERVO
STOP
UNLOCK
STEP
START
LIGHT ON
SELECT
KEY LOCK
BACK LIGHT OFF
Cutting of the power
supply of the machine.
Turn off the breaker
to which the ma-
chine is connected.
Observe the following items before placing your hand or other part of your
body in an active part of the machine in order to feed production material,
change machine set-up, or adjust machine settings.
You may be injured if the machine is actuated. Also you may be struck by an electric shock.
There are three levels of procedure, shown below, for each kind of work.
For repairing the control box. ---------------------------------- Cutting off the power suly of the machine.
This is used to turn off power supply normally. ----------- Power supply OFF
For replacing the control part such as the sensor
For disassembling or replacing parts
For changing production board and daily inspection ---- Servo switch OFF
For placing or removing board on the conveyor
For setting production materials such as the feeder
SP28P-DH/D (The explanation by using SP28P-DH illustration)
M73EB
R
E
L
E
A
S
E
T
R
I
P
O
F
F
O
N
R
E
S
E
T
Turn off the power.
Turn off the servo
switch.
Front panel
1E4C-AA00
2
321
1E4C-E-XXA00-A03-00
WARNING
1
3
