Page 1-8
1. Board holder connects with the clean-
ing unit, and moves to the cleaning
position.
2. Vacuum nozzle rises up, and cleans
the mask.
3. The board holder moves to the
standby position of the cleaning unit,
and it separates.
Production Process
4 Cleaning mask
• Solder on the back of mask is removed.
Mask
Cleaning unit
1B4C-038E
1E4C-E-OMA01-A02-00
