AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
General
2. General
2.1 Product information
This system manual applies to the following Pepperl+Fuchs GmbH equipment:
The AS-i/Gateway with integrated Safety Monitor combines two devices in one
housing: an
AS-i 3.0 EtherNet/IP Gateway and a Safety Monitor for 2 AS-i circuits.
The safety unit provides 4 inputs which can be defined as either EDM or as
START inputs.
The EtherNet/IP Gateway serves to connect AS-i systems to the superordinate
EtherNet/IP controller.
All possibilities offered by AS-i can be used via EtherNet/IP.
Commissioning, debugging and setting up of the AS-i parameters can be accom-
plished with the use of push-buttons, the display and the LEDs, but it can also be
handled via Ethernet TCP/IP or via the diagnostic interface.
AS-i 3.0 EtherNet/IP Gateway, 2 Master with duplicate
address' recognition and AS-i inspector, integrated
Safety Monitor (16 release circuits)
VBG-EN-K30-DMD-S16
Tab. 2-1.
Functions of the device
–
2 master
Relais circuits
AS-i
Master, power supply
Diagnostic interface
Semiconductor outputs
SaW outputs
Safety relays
VBG-EN-K30-DMD-S16 16 2 2 RS 232 2 16 2
Tab. 2-2.
Caption
2 master: The device is a double master
Relais circuits: number of release circuits
16: safety unit generates 16 independent switching signals
AS-i: number of AS-i circuits
2: safety unit functions with two equal AS-i circuits
Master, power supply: 2: The unit contains two AS-i Masters.
Diagnostic interface: type of the diagnostic port
Semiconductor outputs: number of semiconductor outputs
Tab. 2-3.
