AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
This menu indicates which configuration is loaded in the external Safety Monitor.
9.6.5 FAULT DETECTOR
Main menu || DIAGNOSIS || FAULT DETECTOR ||
The menu FAULT DETECTOR displays information about the AS-i fault detector
and permits deleting the AS-i fault detector´s history. Furthermore, a list of abbre-
viations in clear text is displayed in the HELP section.
By selecting RESET the history of the AS-i fault detector can be deleted.
The section HISTORIC lists the error messages generated by the AS-i fault de-
tector since the last RESET.
MONITOR CONFIG
ASI ADDR: 10
SIM. SLAVES: 3
MON. VER.: 1.0
RELEASE DATE:
2006/06/17 18:43
BY:
ROLF BECKER
CONFIG NAME:
L3040 MIT LADEVO
RRICHTUNG LINK U
ND PALETTENWECHS
LER V1.23
RELEASE CODE:
1BDF
FAULT DETECTOR
RESET
HISTORIC:
EFLT OVRV NOIS
ACTUAL:
EFLT OVRV NOIS
DUP ASI ADR:
0 | 31B
HELP:
EFLT EARTH FAULT
OVRV OVERVOLTAGE
NOIS NOISE
DUP ASI ADDR
DUPLICATE ASI
SLAVE ADDRESS
