Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
15
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
Issue date: 17.4.2009
AS-Interface
Spezifications
4. Spezifications
4.1 Technical data
4.1.1 Data sheet VBG-EN-K30-DMD-S16
Attention!
The AS-I power supply for the AS-I components must have isolation per IEC 60
742 and be able to handle momentary power interruptions of up to 20 ms. The
power supply for the 24 V supply must also have isolation per IEC 60 742 and be
able to handle momentary power interruptions of up to 20 ms. The maximum out-
put voltage of the power supply must also be less than 42 V in case of a fault.
VBG-EN-K30-DMD-S16
Ethernet/IP interface RJ-45
Baud rates 10/100 MBaud
Serial interface RS 232
AS-i cycle time 150 Ps
*
(number of slaves + 2)
Safety monitor
Release circuit 4-channel
Start delay < 10 s
Respond delay < 40 ms
Inputs:
4 x EDM/Start
EDM: inputs of external device monitoring circuits
start: start inputs
switching current statical 4 mA at 24 V, dynamic 30 mA at 24 V (T=100 µs)
Output:
4 x output switching elements
relay outputs (output circuits 1 and 2)
max. contact load: 3 A AC-15 at 30 V, 3 A DC-13 at 30 V
semiconductor outputs (output circuits 3 and 4)
max. contact load: 0,5 A DC-13 at 30 V
Card slot chip card for storage of configuration data
Displays
LCD indication of slave addresses and error messages
LED power power on
LED net Ethernet/IP master recognized
LED config error configuration error
LED U AS-i AS-i voltage OK
LED AS-i active AS-i normal operation active
LED prg enable automatic addresses programming enabled
LED prj mode configuration mode active
LED AUX auxiliary power
