AS-Interface
Operation in advanced display mode
9.5 AS-I SAFETY
Main menu || AS-I SAFETY || CODEFOLGEN ||
This menu enables the following functions:
QUICK SETUP
AS-I SAFETY
DIAGNOSIS
SLAVE ADR TOOL
TEST
SETUP
DISPLAY CONTRAST
TEACH CODES
SAFE OUTPUT CH.
SAFE COUPLING
START/STOP
CLEAR SAFE CFG
PIN
SAFE CHIPCARD
PROTECT
SAFE SUBST VAL
TEACH CODES: Teaching the code sequences using the display
SAFE OUTPUT CH: Display function for the status of the individual channels
SAFE COUPLING: Generating safe coupling slaves on the second AS-i circuit
(Optional Menu)
1
1. This function is only displayed if no coupling slaves were entered in the configuration.
START/STOP Changing mode
Safe operating mode / configuration mode
CLEAR SAFE CFG: Deleting the safe configuration
PIN: Changing the PIN number
SAFE CHIPCARD: Chip card configuration
PROTECT: Protecting the configuration on the chip card
SAFE SUBST VAL: Activation/deactivation of the code substitute function for safe
slaves
