9.5.7 SAFE CHIPCARD
Main Menu || AS-I SAFETY || SAFE CHIPCARD ||
In this menu you can manage the safe area of the chip card.
SAFE CHIPCARD
ACTIVE: BANK B
VIEW
CARD -> MONITOR
MONITOR -> CARD
CLEAR CODES
CLEAR SAFE CARD
ACTIVE: BANK X Displays the active bank on the chip card.
VIEW: Reads out the safety configuration of a chip card bank.
CARD->MONITOR: Copies the configuration of a chip card bank to the Monitor.
MONITOR->CARD: Copies the Monitor configuration to a chip card bank.
CLEAR CODES: Deletes the safety configuration on the Monitor.
CLEAR SAFE CARD: Deletes a safe memory bank on the chip card.
