Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
97
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
Issue date: 17.4.2009
AS-Interface
Operation in advanced display mode
9.6.11 ACTUAL CONFIG (actual slave configuration)
Main menu || DIAGNOSIS || ACTUAL CONFIG ||
This function displays the status of the actual configuration of the individual AS-i
slaves.
A help appears at the end of the list explaining the abbreviations:
After selecting the desired AS-i slave address, the values for the current configu-
ration data are displayed after the respective address in the following order:
• IO (I/O-Configuration)
• ID (ID-Configuration)
• xID1 (extended ID1)
• xID2 (extended ID2).
ACTUAL CONFIG
0A | 1A-C
....
30A-X | 31A-D
| 1B-X
....
30A | 31B-F
HELP:
X O.K.
D DETECTED ONLY
UNKNOWN SLAVE
P PROJ. ONLY
MISSING SLAVE
C TYPE CONFLICT
F PERIPH. FAULT
A DUPLICATE ADDR
X (O.K.): The configuration data for the detected AS-i slave agree with
the designed in configuration data.
D (Detected Only): An AS-i slave is detected at this address, but it was not
designed in.
P (Projected Only): An AS-i slave was designed in at this address, but it was not
detected.
C (Type Conflict): The configuration data for the detected AS-i slave do not
agree with the designed in configuration data. The actual exist-
ing configuration of the connected AS-i slave is displayed.
F (Periph. Fault): The AS-i slave has a peripheral error.
A (Duplicate Adr.): Two AS-i slaves at the indicated address.
