AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.9.7.1 CONTROL INFO (Status of the control program)
Main menu || SETUP || AS-I CONTROL || CONTROL INFO ||
This function displays the current status of the AS-i control (control program).
9.9.7.2 CONTROL RUN (start or stop the control program)
Main menu || SETUP || AS-I CONTROL || CONTROL RUN ||
This function is used to start or stop the control program. It modifies the START
BIT in the Control Info menu.
CONTROL INFO
START BIT SET
RUNNING
CYCLE TIME
ACT: 2MS
MAX: 5MS
START BIT SET: The control program has been started.
START BIT RESET: The control program has been stopped.
RUNNING: The control program is running.
STOPPED: The control program has stopped. If, for instances, a configu-
ration error occurs or if the master is in the configuration mode,
the control program can be stopped even if the start bit is set.
CYCLE TIME ACT: Current cycle time of the control program.
CYCLE TIME MAX: Maximum cycle time of the control program since its last start.
CONTROL RUN
RUN
CHANGE
RUN: The control program has been started. The control program
can be stopped even if the start bit is set, for example if a con-
figuration error occurred or if the master is in configuration
mode.
STOP: The control program has been stopped.
CHANGE: Change the state between RUN and and STOP.
