AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
The analog outputs can be changed after selecting an AS-i slave.
9.8.7 PARAMETER
Main menu || TEST || PARAMETER ||
This function displays the hexadecimal value of the current AS-i parameters for
all AS-i slaves.
The current AS-i parameters can be changed after selecting a slave address.
9.9 SETUP (configuration of the AS-i network)
Main menu || SETUP ||
In the "Setup menu", the following sub menus are available:
ANALOG OUT 1
0 +2500
1 +17898
2 +32767 OVERFL
3 -20023
PARAMETER
| 1A - 0
2A - 2| 3A - F
4A - E| 5A - 3 ⇓
OPERATION MODE
STORE ACTUAL CFG
FORCE OFFLINE
AUTO ADR ENABLE
ADR. ASSISTENT
AS-I CONTROL
LOS
CHIPCARD
LANGUAGE
FACTORY RESET
SMILEY
