AS-Interface
Operation in advanced display mode
The section ACTUAL lists the currently present error messages of the AS-i fault
detector.
The following error messages are displayed:
• Duplicate address (displaying of 2 lowest slave addresses with duplicate
addresses)
• Earth faults
•Noise
• Over-voltage
Optionally, the absence of the redundant 24 V for some single masters may be
displayed.
9.6.6 DELTA LIST
Main menu || DIAGNOSIS || DELTA LIST ||
The Delta List is a list of AS-i slaves with configuration error.
9.6.7 LCS (History of the slaves which have triggered a configuration error)
Main menu || DIAGNOSIS || LCS ||
DELTA LIST
0- | 1A-X
2A-X | 3A-X
4A-X | 5A-X
....
30A-X | 31A-
| 1B
2B- | 3B
....
30B | 31B
LCS LIST OF
CORRUPTED SLAVES
RESET
| 1A-X
2A- | 3A-
4A-X | 5A-X
....
30A-X | 31A-
| 1B-X
2B-X | 3B-X
4B-X | 5B-X
....
30B-X | 31B-X
