AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
EtherNet/IP interface
11.1.7 Short Command Interface Object
Class Code: 104 (0x68)
1 instance
11.1.8 Long Command Interface Object
Class Code: 105 (0x69)
1 instance
For special details acc. the command interface commands see the separat manu-
al.
11.1.9 Safety Control Status Internal Monitor
Class Code: 106 (0x6A)
1 instance
Attribute
ID
Access
Rule
Name DeviceNet
data type
Default
data value
100 (0x64) get/set content
command
toggle-bit and as-i circuit
data
ARRAY[12] of
USINT
[0]
[1]
[2 … 11]
Tab. 11-25.
Attribute
ID
Access
rule
Name DeviceNet
data type
Default
data value
100 (0x64) get/set content
command
toggle-bit and as-i circuit
data
ARRAY[38] of
USINT
[0]
[1]
[2 … 37]
Tab. 11-26.
Attribute
ID
Access
rule
Name DeviceNet
data type
Default
data value
100 (0x64) get safety status
relais circuit 1
safety status
relais circuit 2
…
safety status
relais circuit 16
ARRAY[16] of
USINT
[0]
[1]
[2 … 14
[15]
101 (0x65) get/set safety control USINT
Tab. 11-27.
