AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
Using this menu you can delete the safe configuration from a chip card bank. This
procedure is PIN protected.
9.5.8 PROTECT (protect safe configuration)
Main Menu|| AS-I SAFETY || PROTECT ||
This function allows you to protect the safe configuration before downloading
over the serial interface.
9.5.9 SAFETY SUBST VAL (Substitute values for input data from safe slaves)
Main menu || AS-I SAFETY || SAFETY SUBST VAL ||
When working with a double master (AS-i master and two AS-i circuits) the AS-i
circuit must be selected first by using the arrow and the OK buttons.
STOP MONITOR
OK
START MONITOR
OK
PROTECT
ENTER PIN
0000
OK
AS-i CIRCUIT 1
AS-i CIRCUIT 2
SAFE SUBST VAL
SUBSTITUTE
CHANGE
