Pepperl+Fuchs VBG-EN-K30-DMD-S16 - Advanced Diagnostics Object

To Next Page

To Previous Page

Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany

127

Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com

Issue date: 17.4.2009

AS-Interface

EtherNet/IP interface

11.1.6 Advanced Diagnostics Object

Class Code: 103 (0x67)

1 instance for each AS-i circuit

Error counter:

Attribute

Access

rule

Name DeviceNet

data type

Default

data value

100 (0x64) Get/Set LOS (List of offline slaves) ULINT

101 (0x65) Get error counter A ARRAY[32] of USINT

102 (0x66) Get error counter B ARRAY[32] of USINT

Tab. 11-22.

Single- and A slaves

Index error counter

1slave 1/1A

2slave 2/2A

3slave 3/3A

……

31 slave 31/31A

Tab. 11-23.

B slaves

Index error counter

1slave 1B

2slave 2B

3slave 3B

……

31 slave 31B

Tab. 11-24.
