AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.8 TEST (Test tools for slaves)
Main menu || TEST ||
After selecting the menu TEST a warning message is displayed, pointing out, that
it is possible during this test that outputs are set and that the host may loose con-
trol over the network.
Pressing the OK button continues with the actual test, ESC/SERVICE cancels the
process.
The menu TEST contains the following sub-menus:
9.8.1 AS-I CIRCUIT (Selecting the AS-i circuit)
Main Menu || TEST ||
Information!
When working with a double master (AS-i master and two AS-i networks) the AS-i net-
work must be selected first by using the arrow and the OK buttons.
AS-i CIRCUIT 1
AS-i CIRCUIT 2
WARNING:
OUTPUTS MAY BE
SET AND HOST MAY
LOOSE CONTROL.
SLAVE TEST TOOL
BINARY INPUTS
BINARY OUTPUTS
ANALOG INPUTS
ANALOG OUTPUTS
PARAMETERS
SLAVE TEST TOOL: Testing the selected slave
BINARY INPUTS: State of the binary inputs
BINARY OUTPUTS: State of the binary outputs
ANALOG INPUTS State of the analog inputs
ANALOG OUTPUTS: State of the analog outputs
PARAMETERS: Value of the current AS-i parameter
AS-i CIRCUIT 1
AS-i CIRCUIT 2
