Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
71
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
Issue date: 17.4.2009
AS-Interface
Operation in advanced display mode
The grafical symbols indicate the state of the contacts:
Press the OK key to save the learned code table or press ESC to discard it.
9.5.1.3 COUPLING SLAVE
Main Menu || AS-I SAFETY || TEACH CODES || COUPLING SLAVE ||
This menu point allows you to teach the code table for a coupling slave. To con-
tinue, enter the PIN and confirm with OK.
In the following menu you select the AS-i circuit.
After selecting the AS-i circuit the safe unit switches to configuration mode.
Then enter the slave address.
The teach procedure was successful if after approx. 2 s an OK appears in the dis-
play.
Save with OK, or cancel the process by pressing ESC.
Message Description
RR Both contacts open
RX Left contact open, right contact closed.
XR Right contact open, left contact closed.
TEACH CODES
ENTER PIN
0000
OK
AS-i CIRCUIT 1
AS-i CIRCUIT 2
COUPLING SLAVE
SLAVE ADDR. ––1
ESC
COUPLING SLAVE
SLAVE ADDR. ––1
ESC [OK]
