Issue date: 17.4.2009
AS-Interface
Operation in advanced display mode
The data of the B slaves starts at channel 2!
The order in which information is displayed is as follows:
• AS-i slave address
• decimal 16-bit value
• bar graph
If the selected slave is a transparent slave, the value is always displayed without
sign. If the selected slave is a transparent slave, the value is always displayed
without sign. In this case, when the value is changed only positive values can be
entered. Additionally, a value overflow is indicated by "Overfl".
9.8.6 ANALOG OUTPUTS
Main menu || TEST || ANALOG OUTPUTS ||
This function displays the values of the analog outputs for all AS-i slaves.
The order in which information is displayed is as follows:
• AS-i slave address
• decimal 16-bit value
• bar graph.
If the selected slave is a transparent slave, the value is always displayed without
sign. If the selected slave is a transparent slave, the value is always displayed
without sign. In this case, when the value is changed only positive values can be
entered. Additionally, a value overflow is indicated by "Overfl".
AB: A+B Slave
...
ANALOG IN 1
0 +2500
1 +17898
2 +32767 OVERFL
3 -20023
ANALOG OUTPUTS
1 X
2 A
3 B
