AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.6.3.3 MONITOR CONFIG (configuration of the int. monitor)
Main menu || DIAGNOSIS || INT MONITOR || VIEW CONFIG || MONITOR CONFIG ||
This menu indicates which configuration is loaded in the integrated Safety Moni-
tor.
9.6.4 EXT SAFETY MON (external monitor)
Main menu || DIAGNOSIS || EXT MONITOR || EXT SAFETY MON ||
The AS-i Safety Monitor diagnostics reads the diagnostics data from the AS-i
Safety Monitor and shows this diagnostics data in the display.
The menu item ADDRESS can be used to select the desired external monitor.
For additional information, please refer to the <ASIMON> documentation.
Generation 2 external monitors always have unsorted diagnostics.
INT MONITOR
DIAGNOSIS
LAST DIAGNOSIS
VIEW CONFIG
MONITOR CONFIG
COMPLETE
CONFIGURATION
FGDG
MON.VER.: 3.0
RELEASED
BY SA
ON 2007/11/15
AT: 14:30
RELEASED CODE:
81FE
EXT SAFETY MON
DIAGNOSIS
ADDRESS 10
MODE: SORTED/V1
OK
