AS-Interface
EtherNet/IP interface
11.1.2 Assembly Object
Class code 4 (0x04)
number of instances: 72
The Assembly Object bandles data from the application objects.
The Assembly Object Instances consist of (in case of a double master):
• A-slaves and/or single slaves from circuit 1
• single, A- and B-slaves (all slaves) from circuit 1
• A-slaves and/or single slaves from both circuits
• single, A- and B-slaves (all slaves) from both circuits
• No 16-bit data
• 16-bit data from slaves 29…31 from circuit 1
• 16-bit data from slaves 29…31 from both circuits
• No command interface
• Short command interface
• Long command interface
Instances 100 (0x64)…135 (0x87) can only be read, while instances 136
(0x88)…171 (0xAB) can be read and written.
Attribute ID Access Rule Name Data value
3 Data item(s)
Warning!
Don't use "Change of State" for Assembly, if you have slaves with fast input change!
Information!
The are only instances 100 (0x64)…105 (0x69) and 109 (0x6D)…114 (0x72) in case of
a single master.
Assembly instance Data item
Input Output Size
(byte)
Digital Analog Command inter-
face
100 (0x64) 136 (0x88) 16 AS-i circuit 1,
single- and A-Slaves
101 (0x65) 137 (0x89) 28 AS-i circuit 1,
single- and A-Slaves
short
102 (0x66) 138 (0x8A) 54 AS-i circuit 1,
single- and A-Slaves
long
103 (0x67) 139 (0x8B) 40 AS-i circuit 1,
single- and A-Slaves
AS-i circuit 1,
analog slaves 29 .. 31
104 (0x68) 140 (0x8C) 52 AS-i circuit 1,
single- and A-Slaves
AS-i circuit 1,
analog slaves 29 .. 31
short
Tab. 11-9.
