AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.4 QUICK SETUP
Main menu || QUICK SETUP ||
This menu enables a quick configuration of the AS-i network.
Pressing "OK" switches the user to the sub menu "Store AS-i Configuration".
Store+Run
Pressing "OK" stores the detected configuration and the detected slaves on the
AS-i network as the active configuration. The gateway then switches to the pro-
tected operating mode.
Store + Prj Mode
Pressing "OK" stores the detected configuration and the detected slaves on the
AS-i network as the active configuration. The gateway remains in configuration
mode.
Pressing "ESC" leaves this menu and switches back to the main menu.
QUICK SETUP
AS-I SAFETY
DIAGNOSIS
SLAVE ADR TOOL
TEST
SETUP
LCD CONTRAST
WARNING:
OUTPUTS CAN BE
RESET!
Warning!
Outputs can be reset!
STORE AS-I
CONFIGURATION
STORE + RUN
STORE + PRJ MODE
