AS-Interface
Operation in advanced display mode
This menu displays the diagnosis at the time the Safety Monitor was deactivated.
For additional information, please refer to the <ASIMON> documentation.
9.6.4.3 ACTUAL CONFIG (Configuration for the external monitor)
Main menu || DIAGNOSIS || EXT MONITOR || VIEW CONFIG || MONITOR CONFIG ||
EXT SAFETY MON
LAST DIAG CH1
STATUS: OK
CH1.: OFF
CH2.: ON
A COLOR P
32 RED 01
33 GREY 01
34 YEL FL 01
....
HELP:
A DEVICE ADDR.
P DEVICE FROM
00 PREPROCES.
01 CIRCUIT1
10 CIRCUIT2
11 BOTH CIR.
+ CHANGED
Information!
If the diagnosis is read using DIAG INDEX, the device count begins at 0, otherwise at
32!
Complete: The complete diagnostic is read out.
DIAG INDEX: The diagnostic is shown as it was configured under the
"device_index_assignment" in ASIMON
EXT MONITOR
LAST DIAGNOSIS
VIEW CONFIG
