Pepperl+Fuchs VBG-EN-K30-DMD-S16 User Manual

Subject to reasonable modifications due to technical advances. © Pepperl+Fuchs, Printed in Germany
37
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 Internet http://www.pepperl-fuchs.com
Issue date: 17.4.2009
AS-Interface
Electrical connection
7. Electrical connection
7.1 Overview of terminals, indicators and operating elements
7.1.1 VBG-EN-K30-DMD-S16
Legend:
[1] LEDs
[2] EtherNet/IP interface
[3] LC display
[4] Buttons
[5] Terminals: Supply voltage and AS-i circuit
[6] Terminals: Safety monitor
[7] Chip card slot
[8] RS 232 diagnostics port
1
1. Only together with ASIMON 3 G2 Software or AS-i Control Tools
+
-
+
-
+
-
5 ... 6 mm / PZ2
0,8 Nm
7 LB.IN
2 x (0,5 .... 1,5) mm
2
2 x (0,5 ..
.. 1,5) mm
2
AWG 2 x 24 ...12
10
10
[1]
[3]
[4]
[5]
[6]
[2]
[6]
[7]
[8]
[1]
