AS-Interface
Operation in advanced display mode
9.9.1 AS-I CIRCUIT
Main menu || SETUP ||
To start this setup menu, an AS-i circuit must first be selected using the arrow and
the OK buttons.
The function is only available for AS-i masters with two AS-i circuits.
9.9.2 OPERATION MODE
Main menu || SETUP || OPERATION MODE ||
This function shows the current operation mode of the AS-i master:
The operation mode can be changed with "Change".
Parameters and configuration data can be modified in configuration mode, only.
9.9.3 STORE ACTUAL (store currently detected configuration)
Main menu || SETUP || STORE ACTUAL||
This function can only be executed in configuration mode.
This function enables currently detected slaves on the selected AS-i network to
be stored in the configuration of the AS-i Master.
OPERATION MODE: operation mode of the AS-i master
STORE ACTUAL CFG: store current configuration
FORCE OFFLINE: switch AS-i Master to offline operation
AUTO ADR ENABLE: enable automatic address
ADR. ASSISTENT: AS-i address assistant
AS-I CONTROL: status of the control program
LOS: list of offline slaves
CHIPCARD: chipcard
LANGUAGE: select menu language
FACTORY RESET: reset to factory settings
AS-i CIRCUIT 1
AS-i CIRCUIT 2
OPERATION MODE
CONFIG MODE
CHANGE
PROTECTED MODE: protected operating mode
CONFIG MODE: configuration mode
STORE ACTUAL
CONFIGURATION
STORE
