AS-Interface
Operation in advanced display mode
9.2 Navigating through the advanced display mode
The device starts up in the classical mode. Pressing the OK button switches to
the advanced mode. To return to the classical mode, the ESC/service button must
be pressed several times.
In the advanced mode, the selection menu can be moved up and down by using
the two arrow buttons. Pressing OK switches to the selected function or to the
displayed menu, respectively. Pressing ESC/service returns to the previous
menu.
To edit a value it must be highlighted by using the selection bar and then press-
ing OK. The data can be changed by using the arrow-buttons. Changes are con-
firmed with OK. The ESC/service button cancels the editing process.
All possible slave addresses are displayed in sequence from 1 A to 31 A and
from 1 B to 31 B. Data for single slaves are displayed along with the addresses
1 A to 31 A.
Warning!
Classical (Traditional) mode does not guarantee any protection of the settings of the
device!
In the classical mode, it is possible to change settings while the device is in operation.
This can lead to failures of the installation/process (for example changing the address
of an AS-i slave).
☺ Press OK for Menu
Output Circuit
1:ON 2:OFF
ETHERNET/IP
QUICK SETUP
AS-I SAFETY
DIAGNOSE
SLAVE ADR TOOL
TEST
SETUP
DISPLAY CONTRAST
Information!
Some of the settings in the advanced mode are protected as long as the upstream
fieldbus running. That means that some status information can be displayed only.
To protect the installation/process, many options such as "change address", "write
parameter", "set outputs", etc. cannot be performed with an active connection to the
control system (active fieldbus connection) . In order to execute these commands via
the display, the connection to the control system must be deactivated first (no field-
bus connection).
