AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
9.8.3 BINARY INPUTS
Main menu || TEST || BINARY INPUTS ||
This function displays the state of the binary inputs for all AS-i slaves.
9.8.4 BINARY OUTPUTS
Main menu || TEST || BINARY OUTPUTS ||
This function displays the state of the binary outputs for all AS-i slaves.
The binary outputs can be modified after selecting an AS-i slave.
9.8.5 ANALOG INPUTS
Main menu || TEST || ANALOG INPUTS ||
The slave types are characterized as follows:
BINARY INPUTS
D3...D0
1A - 0 1 0 1
2A - 0 1 0 1
3A - 0 0 0 1
⇓
0: Input cleared
1: Input set
BINARY OUTPUTS
D3...D0
1A - 0 1 0 1
2A - 0 1 0 1
3A - 0 0 0 1
⇓
0: Output cleared
1: Output set
ANALOG INPUTS
1 X
2 A
3 B
X: Single Slave
A: A-Slave
B: B-Slave
