AS-Interface
Operation in advanced display mode
9.3.2 ETHERNET OBJECT
Main menu || ETHERNET/IP || ETHERNET OBJECT ||
This menu corresponds to the EtherNet/IP Ethernet Link Object (Object code F6)
and provides information on the following ethernet properties:
Information!
Restat the gateway to assume your changes.
TCP/IP OBJECT
ETHERNET OBJECT
IF SPEED
IF STATUS
PHYSICAL ADDR.
IF COUNTERS
MEDIA COUNTERS
IF SPEED: Attribute 1: Interface speed (displays the instantaneous data
transmission speed)
IF STATUS: Attribute 2: Interface flags
(displays the connection status of the ethernet interface)
PHYSICAL ADDR.: Attribute 3: physical address
(displays the ethernet address)
IF COUNTERS: Attribute 4: Interface counters
(displays the ethernet packet counters)
MEDIA COUNTERS: Attribute 5: Media-Specific counters
(displays the status of ethernet specific counters)
Information!
Not all RFC1213 counters are implemented.
Information!
Not all RFC1642 counters are implemented.
