AS-i 3.0 EtherNet/IP Gateway with integrated Safety Monitor
Operation in advanced display mode
In addition, the status of the configuration is shown in plain text.
If no AS-i slave is present at an address and none is designed in, four decimal
points are displayed instead of the configuration data.
9.6.12 AS-I MASTER (Info)
Main menu || DIAGNOSIS || AS-I MASTER ||
This function shows information about the version and features of the AS-i mas-
ter:
0A - .... -
1A - 7A28 -C
WRONG TYPE
SWID:
41655
COMMAND INTERF
2
MASTER CPU:
41560
FEATURE STRING
.B..DC2.
OA.AU.T
MONITOR VERSION
04.01
SAFE CPU A:
41325
SAFE CPU B:
41326
UART 1:
34866
UART 2:
34866
Information Meaning
SWID Software ID for the host prozessors
COMMAND INTERFACE Revision of the command interface
MASTER CPU Software ID of the master prozessor
FEATURE STRING Feature string for the AS-i master
MONITOR VERSION Monitor version
SAFE CPU A Software ID for the Safe CPU A
SAFE CPU B Software ID for the Safe CPU B
To Next Page
