AS-Interface
Operation in advanced display mode
This function can be used to reset the master to the factory default settings. The
“Reset” is done by selecting menu point DO RESET.
9.10 DISPLAY CONTRAST (set display contrast)
Main Menu || DISPLAY CONTRAST ||
This function allows you to set the display contrast.
• Use the arrow keys to select the line with the bar
• Confirm your selection with OK (bar flashes)
• Use the arrow keys to set the display contrast
• Use OK to apply the setting
The factory settings are invoked from the DEFAULT field.
If the contrast is set so that the display can no longer be read, it can be reset to
the factory default setting as follows:
• Shut the unit off
• Press the MODE and SET keys and hold them down.
• Shut the unit on.
Warning!
This function should be used only in emergencies, since all previously set attributes are
set back to the factory setting and ,thus, secure communication and operation of the
masters with the AS-i network is no longer guaranteed.
Master and AS-i network have to be reconfigured after a successful "Reset".
For double masters the "Reset" acts on both AS-i masters!
DISPLAY CONTRAST
DEFAULT
__________________
